Goldring Eroica-LX Cartridge

Goldring Cartridges

Price: $505.27
No VAT
Quantity
  • In stock - Shipping Status
  • pack1_ local-shipping Created with Sketch.
    Tracked Shipping - Rates to
  • pack1_ lock Created with Sketch.
    Secure payment by Paypal & Stripe
The Eroica LX is a true audiophile moving-coil cartridge featuring the famous Gyger II diamond stylus profile. A nude, fine-line elliptical type with a 6 µm lesser radius, it gives smooth, extended highs, low distortion and reproduces a highly detailed and dynamic sound. (?) The low output Eroica LX offers an exceptionally high standard of performance and reliability and must be used with an amplifier which features a dedicated moving coil phono input.
GOLDRING
GL0015M

Data sheet

Frequency response
20 Hz - 22 kHz ± 2 dB
Static compliance
30 mm/N
Vertical tracking angle
24 °
Dynamic compliance
@ 10 Hz18 mm/N
Channel separation
better than 25 dB @ 1 kHz
Stylus radius
Gyger II
Channel balance
within 1 dB @ 1 kHz
within 1 dB @ 1 kHz
Cartridge mass
(inc fixings)6.6 g
5.5 g
Stylus Type
Non-Replaceable
Load resistance
100 Ω
Load capacitance
100 - 1000 pF
Internal resistance
8 Ω
Internal inductance
12 µH
Sensitivity
0.5 mV ± 1dB 1kHz @ 5 m/s
Playing weight
1.5 - 2.0 g (1.7 g nom.)
Fixing centre
0.5 " (12.7 mm)
Equivalent tip mass
0.35 mg
